Adjustment
of
carbonated
water
ow.
Thisvalvehasasingleowrestrictor,notaow
regulator. These can be adjusted using a 6mm
hexagon Allen key.
Carbonatedwaterowadjusterscrew.
Toincreaseow,turnadjusteranti-clockwise.
The adjuster is accessed by removing the cap in
the membrane switch panel
20
Section 3
19
21
