NAD T 751 User Manual

47
ELECTRICAL PARTS LIST
Reference No. Part No. Description
AC3 BOARD ASSEMBLY
PC BOARD
2701 PCB-N0910C-AC3 PCB ASSY AC3 N091XC
CAPACITORS
C101 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
C102 150E-104M-J-BD CC 25V 0.1µF20% 0805 1.2x2.0
C103 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
C104 157C-108M-5-S5 CE 10V 1000µF 20% RL 10x16
C105 150F-103K-J-BD CC 50V 0.01µF 10% 0805 1.2x2.0
C106 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
C107 157D-228M-5-W9 CE 16V 2200µF 20% RL 12x20
C108 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
C114-C115 157D-226M-5-GM CE 16V 22µF 20% RL 4x7
C117, C119 157D-475M-5-EI CE 16V 4.7µF 20% RL 3x5
C120-C121 157D-226M-5-GM CE 16V 22µF 20% RL 4x7
C122-C123 150F-562J-J-BD CC 50V 5600pF 5% 0805 1.2x2.0
C125 150E-104M-J-BD CC 25V 0.1µF20% 0805 1.2x2.0
C126 157D-227M-5-KW CE 16V 220µF 20% RL 6x12
C127 150E-104M-J-BD CC 25V 0.1µF20% 0805 1.2x2.0
C128 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C129 150E-104M-J-BD CC 25V 0.1µF20% 0805 1.2x2.0
C130 157E-105M-5-EI CE 25V 1µF 20% RL 3x5
C132, C134 157D-475M-5-EI CE 16V 4.7µF 20% RL 3x5
C135-C136 150F-562J-J-BD CC 50V 5600pF 5% 0805 1.2x2.0
C138 150E-104M-J-BD CC 25V 0.1µF20% 0805 1.2x2.0
C139 157D-227M-5-KW CE 16V 220µF 20% RL 6x12
C140 150E-104M-J-BD CC 25V 0.1µF20% 0805 1.2x2.0
C141 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C142 150E-104M-J-BD CC 25V 0.1µF20% 0805 1.2x2.0
C143 157E-105M-5-EI CE 25V 1µF 20% RL 3x5
C145, C147 157D-475M-5-EI CE 16V 4.7µF 20% RL 3x5
C148 150F-562J-J-BD CC 50V 5600pF 5% 0805 1.2x2.0
C149 150F-103K-J-BD CC 50V 0.01µF 10% 0805 1.2x2.0
C150-C151 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
C152 150F-103K-J-BD CC 50V 0.01µF 10% 0805 1.2x2.0
C153 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C154 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
C156 150F-683K-J-BD CC 50V 0.068µF 10% 0805 1.5x2.5
C157 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
C158 157D-476M-5-IU CE 16V 47µF 20% RL 5x11
C159 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
C161-C162 15FD-105Z-J-BD CC 16V 1µF +80-20% 0805
C163-C164 150F-103K-J-BD CC 50V 0.01µF 10% 0805 1.2x2.0
C165 157D-225M-5-GM CE 16V 2.2µF 20% RL 4x7
C166-C167 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
C168 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C169 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
C171 15FF-224Z-J-BD CC 50V 0.22µF +80/-20% 0805
C172 153F-225J-5-TOM CM 50V 2.2µF RL 10x8 METALLIZED
C173 157C-107M-5-IU CE 10V 100µF 20% RL 5x11
C174 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C175 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
