OSC RF
9
BLOCK DIAGRAM
DIR
CS-8414
DIG SW
74HC153
DSP
CS-4926
PSU
&
ISC
MONITOR
OUTPUT
VIDEO
INPUTS
DIGITAL
INPUTS
OSD
LC74763
2CH ADC
CS-5331
TC-9273
ANALOG
SWITCH
TUNER
SUBWOOFER
LA1837
LC7218
LC72723
VIDEO SWITCH
BA7625
(4cs)
DAC
CS4340
3pcs, 6ch tot
6CH
VOLUME
M62447SP
5CH
POWER
AMPLIFIER
MCU
LC87F65C8A
VFL DISPLAY
NAD LINK
IN/OUT
REMOTE
SENSOR
KEY
MATRIX
MUTING
5.1CH
INPUT
EEPROM
VIDEO
OUTPUTS
AUDIO
INPUTS
AUDIO
OUTPUTS
10
ADJUSTMENT POINTS DIAGRAM
1. TUNER
2. IDLE CURRENT - Front Amplifier & Surround Amplifier Board
