EXPLODED VIEW PARTS LIST
ITEM Part No. Description
Qty
0101 1403-5160-1 BOTTOM CHASSIS 1
0102*AH 1403-6360-0 REAR PANEL 120V 1
0102*C 1403-6361-0 REAR PANEL 230V 1
0103 1403-5180-0 TOP COVER 1
0104 1403-5190-2 SUB-FASCIA 1
0105 1403-6350-0 FASCIA 1
0106 4154-0301-0 FRONT INPUT BEZEL 1
0107 4134-9031-0 SURR BOARD BRACKET 1
0108 4134-9041-0 AC3 BOARD BRACKET 1
0109 4134-9051-0 ANGLE BRACKET 2
0110 4134-9061-0 PHONES BRACKET 1
0111 4134-9071-0 PCB MOUNTING BRACKET 5
0112 4154-0311-0 DUMMY CLAMP 1
0113 2444-1601-0 POWER BUTTON GREEN LONG 1
0114 3716-4401-0 WINDOW LENS 1
0115 4154-0321-0 TONE CONTROL LOZENGE 1
0116 4152-4341-0 INPUT BUTTON LOZENGE 1
0118 2444-1801-0 TONE KNOB LONG 2
0119 2444-1901-0 DUO BUTTON 2
0120 2444-1301-1 BUTTON RACKER 1
0121 4154-0091-0 BEZEL RACKER 1
0122 2444-2101-0 INPUT BUTTON 4
0123 4154-0411-0 BEZEL DUO 2
0124 4134-9081-0 VOLUME KNOB SKIN 1
0125 4154-0341-0 VOLUME KNOB CORE 1
0126 4152-4631-0 RUBBER FOOT 14MM HIGH 4
0127 4152-4641-0 CUSHION FOOT 4
0128 4152-4331-0 POWER BUTTON BEZEL 1
0129 4154-0331-0 VIDEO COVER 1
0130 4152-1701-0 LED BEZEL 1
0131 3714-5706-0 LED LENS 1
0132 8900-3040-0 DC FAN 12V 80X80MM 1
0133 4152-3851-0 SQ. STRAIN RELIEF BUSHING 1
0134*AH 7009-3100-2 AC CORD 18AWGX2 SPT-2UL/CSA D.INSULATED 1
0134*C 7009-3110-0 AC CORD SEMKO 1
0136 5400-9051-0 HEATSINK 1
0137 4134-0121-0 HEATSINK MOUNTING BRACKET 2
0138 4152-0451-0 L-BRACKET 4
0139 2600-4008-0973 FLAT WASHER M4X0.8X9.7 BZ 4
0140 2607-4010-0703 SPRING WASHER M4X1X7 BZ 4
0141 2904-4010-3000 MACHINE SCREW 4X10MM(BLK.ZN) 4
0142 2954-3008-3000 TAPPING SCREW 3X8MM B-TITE(BLK.ZN) 34
0143 2842-3367-0 METAL WASHER ID=3.3 OD=6.7 4
0144 2900-4006-3010 M4X0.5PX6MM W/FLAT WASHER 6
0146 2904-3008-0000 M3X8MM B-TITL (YEL.ZN) 38
To Next Page
