Chapter 3 Signal Connections

The digital I/O signals of the SCXI-1120/D match the digital I/O lines of

the MIO-16 device. When used with an SCXI-1341, SCXI-1342, or

SCXI-1344 cable assembly, the SCXI-1120/D signals match the digital

lines of the Lab-NB/Lab-PC+/Lab-LC devices and the PC-LPM-16/PnP

device, respectively. Table 3-3 lists the equivalencies. For more

information, consult your cable assembly installation guide.

Specifications and ratings for the digital I/O lines are given in Appendix A,

Specifications.

Table 3-3. SCXIbus to SCXI-1120/D Rear Connector to DAQ Device Pin Equivalencies

SCXIbus Line

SCXI-1120/D

Rear Signal

Connector

MIO E Series

Device

Lab and 1200

Series Device

PC-LPM-16/PnP

MOSI SERDATIN DIO0 PB4 DOUT4

D*/A DAQD*/A DIO1 PB5 DOUT5

INTR* SLOT0SEL* DIO2 PB6 DOUT6

SPICLK SERCLK EXTSTROBE* PB7 DOUT7

MISO SERDATOUT DIO4 PC1 DIN6
