Appendix A Specifications for SCXI-1120D
© National Instruments Corporation A-5 SCXI-1120/D User Manual
SCXI-1120D
Analog Input
Input Characteristics
Number of channels ...............................8 differential
Input coupling ........................................DC or AC with TBX-1329 or
SCXI-1305
Maximum working voltage
(Signal + CMV) .....................................250 V
rms
Overvoltage protection........................... 250 V
rms
on or off
Table A-1.
Input Signal Range
Gain Range
Channel Bandwidth
Filter at 22.5 K Filter at 4.5 K
0.5 ±10 V 22.5 K 4.5 K
1 ±5 V 22.5 K 4.5 K
2.5 ±2 V 22.5 K 4.5 K
5 ±1 V 22.5 K 4.5 K
10 ±0.5 V 22 K 4.5 K
25 ±0.2 V 22 K 4.5 K
50 ±0.1 V 22 K 4.5 K
100 ±50 mV 20 K 4.5 K
250 ±20 mV 20 K 4 K
500 ±10 mV 17 K 4 K
1000 ±5 mV 14 K 3.5 K
