Table 1. Signal Descriptions
Signal Description
AI+ Positive analog input signal connection
AI- Negative analog input signal connection
COM Common reference connection to isolated ground
Grounded Differential Connections
Voltage
Source
+
–
AI+
AI–
COM
NI 9220
NI 9220 Getting Started Guide | © National Instruments | 13
