Figure 3. Powering Multiple Modules from a Single Power Supply
Red (+)
Black (–)
NI P/N 198303-XX:
Male Microfit
Y-Adapter
NI P/N 198159-XX:
Female Microfit
Pigtail
V+
V–
Any 8 to 28 V
Isolated
P
ower Supply
RS485 Bus Topology and Termination
Refer to Figure 4 and Figure 5 for an overview of 4-wire and
2-wire RS485 bus topologies and termination.
