National Instruments NI ELVIS III User Manual

To set up and use the NI ELVIS III, you need the following items:
■
Required hardware
■
NI ELVIS III workstation
■
AC/DC power supply
■
High-speed USB 2.0 cable
■
Computer
■
Recommended items for first time users
■
BNC to BNC cable or
■
Cables and Accessories Kit (786520-01)
■
Optional items and tools for further exploration
■
NI ELVIS III prototyping board
■
Components to build your circuits
■
Cabling and sensors as required for your application
■
Wire cutter
■
Wire stripper
■
Soware
■
NI ELVIS III Soware Bundle Installer (optional)
■
Documentation
■
NI ELVIS III Quick Start Guide
■
NI ELVIS III Safety, Environmental, and Regulatory Information (SERI)
manual
Unpacking Your Device
The NI ELVIS III workstation and the NI ELVIS III Prototyping Board ship in antistatic
packages to prevent electrostatic damage. Electrostatic discharge can damage
several components on the NI ELVIS III hardware.
Notice Never touch the exposed pins of connectors.
ni.com
4
NI ELVIS III Getting Started

National Instruments NI ELVIS III Specifications

General

Form Factor	Benchtop
Connectivity	Ethernet, USB
Supported Protocols	TCP/IP, UDP
FPGA	Xilinx Zynq-7020
Analog Input Channels	8 differential or 16 single-ended
Analog Input Resolution	16 bits
Analog Output Channels	2
Analog Output Resolution	16 bits
Analog Output Max Update Rate	1 MS/s
Digital I/O Channels	40
Operating Temperature	0 °C to 40 °C
Relative Humidity	10% to 90% non-condensing
Category	Network Hardware
Manufacturer	National Instruments
Model	NI ELVIS III
Digital I/O Voltage	3.3 V
Supported Software	LabVIEW
