Figure 2. PXIe-8862 Installed in a PXI Express Chassis
1
2
3
1. PXI Express Chassis
2. PXIe-8862 Controller
3. Injector/Ejector Rail
PXIe-8822/42/62 Front Panel
The following figures show the PXIe-8822/42/62 front panel layouts.
ni.com
6
PXIe-8822/42/62 Getting Started
