NEC 90 User Manual

10
Specifications cont.
Monitor MultiSync
®
70 Notes
Specifications Monitor
Picture Tube Diagonal: 17 inch 90° deflection, 0.28 mm trio dot pitch,
Viewable Image Size: 16.0 inch medium short persistence phosphor,
Radius: 1210 mm multi-layered, anti-static screen coating,
semi-tint screen, Invar Shadow Mask and
OptiClear
®
screen.
Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Display Colors Analog input: Unlimited number of Colors Depends on display card used.
Synchronization Horizontal: 31 kHz to 69 kHz Automatically
Range Vertical: 55 Hz to 120 Hz Automatically
Resolutions Supported 640 x 480 @ 60 to 120 Hz
Some systems may not support
Resolution based on
horizontal and 800 x 600 @ 55 to 109 Hz all modes listed.
vertical frequencies only 832 x 624 @ 55 to 103 Hz
1024 x 768 @ 55 to 85 Hz .......................
NEC cites recommended resolution at
1152 x 870 @ 55 to 76 Hz 75 Hz for optimal display performance.
1280 x 1024 @ 55 to 65 Hz
Active Display Area Horizontal:
310 mm/12.2 inches Dependent upon signal timing used,
(Factory Setting) Vertical: 232 mm/9.1 inches and does not include border area.
Active Display Area 325 mm/12.8 inches Dependent upon signal timing used,
(Full Scan) 244 mm/9.6 inches and does not include border area.
Power Supply AC 100 – 240 V, 50/60 Hz
Current Rating 1.8A @ 100 – 240 V
Dimensions
403 mm (W) x 427 mm (H) x 440 mm (D)
15.9 inches (W) x 16.8 inches (H) x 17.3 inches (D)
Weight 17.5 kg
38.5 lbs
Environmental Considerations
Operating Temperature: 0°C to +35°C
Humidity: 30% to 80%
Feet: 0 to 10,000 Feet
Storage Temperature: -20°C to +60°C
Humidity: 10% to 90%
Feet: 0 to 45,000 Feet
NOTE: Technical specifications are subject to change without notice.
15500251.wpc 5/7/99, 12:54 PM12
