NEC 90 User Manual

11
Monitor MultiSync
®
90 Notes
Specifications Monitor
Picture Tube Diagonal: 19.5 inch 90° deflection, 0.26 mm trio dot pitch,
Viewable Image Size: 18.0 inch medium short persistence phosphor,
Radius: 1360 mm multi-layered, anti-static screen coating,
semi-tint screen, Invar Shadow Mask and
OptiClear
®
screen surface.
Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Display Colors Analog input: Unlimited number of Colors Depends on display card used.
Synchronization Horizontal: 31 kHz to 96 kHz Automatically
Range Vertical: 55 Hz to 160 Hz Automatically
Resolutions Supported 640 x 480 @ 60 to 160 Hz
Some systems may not support
Resolution based on
horizontal and 800 x 600 @ 55 to 153 Hz all modes listed.
vertical frequencies only 832 x 624 @ 55 to 144 Hz
1024 x 768 @ 55 to 105 Hz
1152 x 870 @ 55 to 105 Hz
1280 x 1024 @ 55 to 90 Hz .....................
NEC cites recommended resolution at
1600 x 1200 @ 55 to 76 Hz 85 Hz for optimal display performance
Active Display Area Horizontal: 356 mm/14.0 inches Dependent upon signal timing used,
(Factory Setting) Vertical: 267 mm/10.5 inches and does not include border area.
Active Display Area 366 mm/14.4 inches Dependent upon signal timing used,
(Full Scan) 274 mm/10.8 inches and does not include border area.
Power Supply AC 100 – 240 V, 50/60 Hz
Current Rating 2.2A @ 100 – 240 V
Dimensions
447 mm (W) x 462 mm (H) x 482 mm (D)
17.6 inches (W) x 18.2 inches (H) x 19.0 inches (D)
Weight 20.5 kg
45.2 lbs
Environmental Considerations
Operating Temperature: 0°C to +35°C
Humidity: 30% to 80%
Feet: 0 to 10,000 Feet
Storage Temperature: -20°C to +60°C
Humidity: 10% to 90%
Feet: 0 to 45,000 Feet
NOTE: Technical specifications are subject to change without notice.
