English-15
English
Connecting a Personal Computer
Connecting your computer to your LCD monitor will enable you to display your computer’s screen image.
Some video cards with a pixel clock over 162MHz may not display an image correctly.
Your LCD monitor displays proper image by adjusting the factory preset timing signal automatically.
<Factory preset signal timing>
• If you use with a Macintosh PowerBook, set “Mirroring” to Off on your PowerBook.
Refer to your Macintosh’s owner’s manual for more information about your computer’s video output requirements and any
special identification or configuration your monitor’s image and monitor may require.
• Input TMDS signals conforming to DVI standards.
• To maintain display quality, use a cable that conforms to DVI standards.
Connecting a DVD Player with HDMI out
• Please use an HDMI cable with HDMI logo.
• It may take a moment for the signal to appear.
• PC-DVI signals are not supported.
Connecting a Computer with DisplayPort
• Please use DisplayPort cable with DisplayPort certified logo.
• It may take a moment for the signal to appear.
• Please note that DisplayPort connector does not supply power to the connected component.
• Please note that when connecting a DisplayPort cable to a component with a signal conversion adapter, an image may not
appear.
• Select DisplayPort cables feature a locking function. When removing this cable, hold down the top button to release the
lock.
Horizontal Vertical
640 x 480 31.5 kHz 60 Hz
800 x 600 37.9 kHz 60 Hz Compressed image
1024 x 768 48.4 kHz 60 Hz Compressed image
1280 x 768 48 kHz 60 Hz Compressed image
1360 x 768 48 kHz 60 Hz Compressed image
1280 x 1024 64 kHz 60 Hz Compressed image
1920 x 1080 66.6 kHz 60 Hz Recommended resolution
1920 x 480 29.8 kHz 60 Hz Recommended resolution
Resolution
Remarks
Scanning frequency
