Specifications
Product Specifications
LCD Module 43" /109.3 cm diagonal
Pixel Pitch: 0.552 mm
Resolution: 1920 x 480
Color: Over 16 million colors (depending on video card used)
Brightness: 700 cd/m
2
(Max.), 500 cd/m
2
(Typ.) @25°C
Contrast Ratio: 3000:1
Viewing Angle: 89° (typ) @ CR>10
Design View Distance: 1300 mm
Frequency Horizontal: 15.625/15.734 kHz, 29.8 kHz - 91.1 kHz (Analog Input)
29.8 kHz - 91.1 kHz (Digital Input)
Vertical: 50.0 - 85.0 Hz
Pixel Clock 25.2 MHz - 162.0 MHz
Viewable Size 1059.8 x 265.0 mm
Input Signal
DVI DVI-D 24pin Digital RGB DVI (HDCP)
VGA60*
1
, SVGA60, XGA60, WXGA60, SXGA60, UXGA60, 1920X1080 (60Hz), 1920X480 (60Hz)*
1
DisplayPort DisplayPort Connector Digital RGB DisplayPort Complies with Standard V1.1a, applicable to HDCP1.3
VGA60*
1
, SVGA60, XGA60, WXGA60, SXGA60, UXGA60, 1920x1080 (60 Hz), 1920X480 (60Hz)*
1
VGA 15pin Mini D-sub Analog RGB 0.7 Vp-p/75 ohm
VGA60*
1
, SVGA60, XGA60, WXGA60, SXGA60, UXGA60, 1920X1080 (60Hz), 1920X480 (60Hz)*
1
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
RGB/HV BNC (R,G,B,H,V) Analog RGB 0.7 Vp-p/75 ohm
VGA60*
1
, SVGA60, XGA60, WXGA60, SXGA60, UXGA60, 1920X1080 (60Hz), 1920X480 (60Hz)*
1
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
HDMI HDMI Connector Digital RGB HDMI
1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz
DVD/HD1 RCA (Y, Cb/Pb, Cr/Pr) Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
DVD/HD2 BNC HDTV/DVD: 1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
VIDEO1 BNC/RCA Composite 1.0 Vp-p/75 ohm
VIDEO2 BNC NTSC/PAL/SECAM/4.43NTSC/PAL60
S-VIDEO Mini DIN 4 pin S-VIDEO Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3 Vp-p/75 ohm (PAL/SECAM)
NTSC/PAL/SECAM/4.43NTSC/PAL60
Output Signal
RGB/HV BNC (R,G,B,H,V) Analog RGB 0.7 Vp-p with 75 ohm terminated
Separate HV sync: TTL level (Posi / Nega)
DVD/HD2 BNC Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
VIDEO1/VIDEO2 BNC Composite 1.0 Vp-p with 75 ohm terminated
AUDIO
AUDIO RCA (L/R) X2 Analog Audio Stereo L/R 0.5 Vrms
Input STEREO Mini Jack
HDMI Connector Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
DisplayPort Connector Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
AUDIO RCA (L/R) Analog Audio Stereo L/R 0.5 Vrms
Output
Speaker Output External Speaker Jack 15 W + 15 W (8 ohm)
Control RS-232C In: 9 Pin D-sub
RS-232C Out: 9 Pin D-sub (with daisy chain)
LAN: RJ-45 10/100 BASE-T
Remote IN: Stereo Mini jack 3.5
Remote OUT: Stereo Mini jack 3.5
Power Supply 2.8 - 1.2 A @ 100-240VAC, 50/60Hz
Operational Environment Temperature: 5 - 40°C / 41 - 104°F (Default brightness), 5 - 20°C / 41 - 68°F (Max brightness)
Humidity: 20 - 80% (without condensation)
Altitude: 0 - 3000 m (Brightness may decrease with altitude)
Storage Environment Temperature: -20 - 60°C / -4 - 140°F
Humidity: 10 - 90% (without condensation) / 90% - 3.5% x (Temp - 40°C) regarding over 40°C
Dimension 1096 (W) x 300 (H) x 190 (D) mm / 43.1 (W) x 11.8 (H) x 7.5 (D) inches
Weight 19.6 Kg (43.2 lbs)
Mounting interface 500 mm x 200 mm (M6, 4 Holes)
Power Management VESA DPM
Plug & Play VESA DDC2B, DDC/CI, DisplayPort
Accessories Setup manual, Power Cord, Video Signal cable, Remote Control, AA Battery x 2, Clamp x 2,
Screw x 4, CD-ROM, Cable cover
NOTE: Technical specifications are subject to change without notice. *1: The resolution over than the native resolution is compressed image.
