Monitor Adjustment Controls
SELECT
Proceeds to the next control selection. Moves the LED indicator
light across the adjustment controls from left to right.
Horizontal position control (left to right)
Adjusts the horizontal position of the image from left to right.
Vertical position control (up and down)
Adjusts the vertical position of the image up and down.
Horizontal size control (increase and decrease)
Adjusts the horizontal size of the image from wider to narrower.
Vertical size control: (increase and decrease)
Adjusts the vertical size of the image from taller to shorter.
Side pincushion control
Adjusts the curvature of the edges of the left and right side of
the display image either inward or outward. The image should
be adjusted to attain a straight line on the left and right sides.
9
Controls
Control +/–
Increases or decreases the adjustment of the selected
control function.
RESET
Resets image back to factory setting.
Contrast control
Adjusts the image brightness in relation to the background.
Brightness control
Adjusts the overall image and background screen brightness.
Power Switch/Degauss
Turns the power ON or OFF. When the power is ON, the LED
power indicator above the Power Switch is lit. This switch also
acts as a Degauss Switch. On power up the degauss circuitry
eliminates stray magnetic fields that alter the correct scan of the
electron beams and affect the purity of the screen colors, the
focus and misconvergence.
78131481 7/29/98, 8:44 AM11
