APPENDIX C: SPECIFICATIONS
General
Standards
IEEE 802.3, 802.3u, 802.11b and 802.11g
Protocols
TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP
Ports
One 10/100M Auto-Negotiation WAN RJ45 port, Four 10/100M Auto-Negotiation
LAN RJ45 ports supporting Auto MDI/MDIX
Cabling Type
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Radio Data Rate
54/48/36/24/18/12/9/6Mbps or 11/5.5/3/2/1Mbps
Power Supply
9V~ 0.8A
LEDs
Power, System, WLAN, WAN, 1-4
Safety & Emissions
FCC, CE
Environmental and Physical
Operating Temp.
0oC~40oC (32oF~104oF)
Operating Humidity
10% - 95% RH, Non-condensing
Dimensions (WxDxH)
186x146x44 mm (without antenna)
