NETGEAR GS316P User Manual

1. Connect network devices to the ports on the switch.
2. Connect an RJ-45 port on the switch to a network.
Note: ,QDVPDOORIŴFHRUKRPHRIŴFHQHWZRUNFRQQHFWWKHVZLWFKWRWKH/$1
port of a router that, in turn, is connected to an Internet modem.
3. Power on the switch.
PoE considerations
The switch prioritizes the PoE+ power that it supplies in ascending port order
(from port 1 to port 16). If the aggregate power requirements of all attached
power devices (PD) exceed the power budget of the switch, the PD on the
highest-numbered port is disabled to make sure that the PDs that are connected
WRWKHKLJKHUSULRULW\ORZHUQXPEHUHGSRUWVDUHVXSSRUWHGŴUVW
The following tables describe the power adapter models that are compatible with
the GS316P and GS316PP switches and their PoE classes and switch allocations:
Note: The listed total power budget is the maximum power limit for the
switch. Many PDs require less than maximum power, so the aggregate power
requirements are lower than the maximum, allowing all sixteen PoE ports to be
active simultaneously.
Power adapters and total power budgets for the GS316P and GS316PP:
Power adapter model Power adapter Total power budget
EPS90W 90W 76W
EPS130W 130W 115W
EPS200W 200W 183W
PoE classes and switch allocations:
Device
class
Standard Class
description
Minimum power
allocated to the
powered device
Range of power
delivered to the
powered device
0 PoE and PoE+ Default power
(full)
0.44W 0.44W–12.95W

NETGEAR GS316P Specifications

General

Switch type	Unmanaged
Quality of Service (QoS) support	Yes
Power connector	DC-in jack
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Jumbo frames	9216
Latency (1 Gbps)	3.7 µs
MAC address table	4000 entries
Packet buffer memory	1 MB
Packet forwarding rate (1 Gbps)	1448000 pps
Heat dissipation	437.42 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Input current	2.4 A
DC input voltage	54 V
Power consumption (max)	127.9 W
Mean time between failures (MTBF)	2362192 h
Product color	Black
Housing material	Metal
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	102 mm
Width	286 mm
Height	27 mm
Weight	880 g
