Technical specifications for Orbi satellite model RBS40
The following table shows the technical specifications for the satellite.
Table 15. Technical specifications for the satellite
DescriptionFeature
TCP/IP, RIP-1, RIP-2, DHCP, PPPoE, PPTP, Bigpond, Dynamic
DNS, UPnP, and SMB
Data and routing protocols
•
North America: 120V, 60 Hz, input
•
UK, Australia: 240V, 50 Hz, input
•
Europe: 230V, 50 Hz, input
•
All regions (output): 12V, 2.5A DC output
Power adapter
6.4 x 3.1 x 8.0 in. (163 x 78 x 203 mm)Dimensions
1.65 lb (748 g)Weight
0° to 40°C (32º to 104ºF)Operating temperature
90% maximum relative humidity, noncondensingOperating humidity
FCC Part 15 Class B
VCCI Class B
EN 55 022 (CISPR 22), Class B C-Tick N10947
Electromagnetic emissions
10BASE-T or 100BASE-TX or 1000BASE-T, RJ-45LAN
10BASE-T or 100BASE-TX or 1000BASE-T, RJ-45WAN
Maximum wireless signal rate complies with the IEEE 802.11
standard.
12
WiFi
2.4 GHz: Max 400 Mbps
5 GHz Front haul: Max 866 Mbps
5 GHz Back haul: Max 866 Mbps
Radio data rates
IEEE 802.11b/g/n 2.4 GHz–256 QAM support
IEEE 802.11 a/n/ac 5 GHz–256 QAM support
Data encoding standards
Limited by the amount of WiFi network traffic generated by
each node (typically 50–70 nodes).
2.4 GHz: 127
5 GHz (front haul): 127
Maximum number of
computers per wireless
network
User Manual161Supplemental information
Orbi WiFi System
