APPENDIX B: TROUBLESHOOTING
This chapter provides information about troubleshooting the NETGEAR ProSafe GS716T Gigabit Smart Switch. Topics include:
o Troubleshooting chart
o Additional troubleshooting suggestions
Troubleshooting Chart
Table B-1 lists symptoms, causes, and solutions of possible problems.
Table B-1. Troubleshooting Chart
Symptom Cause Solution
Power LED is off No power is received Check the power cord connections for the switch at the
switch and the connected device
Make sure all cables used are correct and comply with
Ethernet specifications
Link/ACT LED is off Port connection is not working Check the crimp on the connectors and make sure that the
plug is properly inserted and locked into the port at both the
switch and the connecting device
Make sure all cables used are correct and comply with
Ethernet specifications. See Appendix D
Check for a defective adapter card, cable, or port by testing
them in an alternate environment where all products are
functioning
File transfer is slow or performance
degradation is a problem
Half- or full-duplex setting on the
switch and the connected device
are not the same
Make sure the attached device is set to auto negotiate
A segment or device is not recognized as
part of the network
One or more devices are not
properly connected, or cabling does
not meet Ethernet guidelines
Verify that the cabling is correct. Be sure all connectors are
securely positioned in the required ports. Equipment may
have been accidentally disconnected
Link/ACT LED is flashing continuously on
all connected ports and the network is
disabled
A network loop (redundant path)
has been created
Break the loop by ensuring that there is only one path from
any networked device to any other networked device
Additional Troubleshooting Suggestions
If the suggestions in Table B-1 do not resolve your problem, refer to the troubleshooting suggestions in this section.
Network Adapter Cards
Make sure the network adapter cards installed in the PCs are in working condition and the software driver has been installed.
Configuration
If problems occur after altering the network configuration, restore the original connections and determine the problem by implementing the new
changes, one step at a time. Make sure that cable distances, repeater limits, and other physical aspects of the installation do not exceed the
Ethernet limitations.
Switch Integrity
If required, verify the integrity of the switch by resetting the switch. To reset the switch, use the Tools> Reset command or remove AC power from
the switch and then reapply AC power. If the problem continues, contact NETGEAR technical support. In North America, call 1-888-NETGEAR. If
you are outside of North America, please refer to the support information card included with your product.
Auto Negotiation
The 10/100/1000 Mbps ports negotiate the correct duplex mode and speed if the device at the other end of the link supports auto negotiation. If the
device does not support auto negotiation, the switch only determines the speed correctly and the duplex mode defaults to half-duplex.
The gigabit port on the Gigabit module negotiates speed, duplex mode, and flow control, provided that the attached device supports auto-
negotiation.
Symptom Cause Solution

NETGEAR Prosafe GS716T Specifications

Network Protocol and Standards Compatibility

Protocol 1	IEEE 802.3 10BASE-T
Protocol 2	IEEE 802.3u 100BASE-TX
Protocol 3	IEEE 802.3ab 1000BASE-T

Performance Specifications

Bandwidth	32 Gbps
Network latency	Less than 20 microseconds
Buffer memory	256 KB

Power

Power Consumption	32 W maximum
Input Voltage	100-240VAC
Frequency	50-60 Hz

Operating Environment

Operating temperature	0 to 40°C
Storage temperature	-20 to 70°C
Operating humidity	90% maximum relative humidity

Weight and Dimensions

Dimensions	1.7 x 17.3 x 8.1 in
Weight	6.03 lbs
Weight in kg	2.74 Kg
