NETGEAR RAX30 User Manual

Rear panel
The following figure shows the rear panel connectors and buttons.
Figure 3. Rear panel
The rear panel contains the following components:
1. Ethernet ports 1–4. Four Gigabit Ethernet RJ-45 LAN ports. Use these ports to
connect LAN devices to the router.
2. Internet port. One Gigabit Ethernet RJ-45 WAN port to connect the router to an
Internet modem such as a cable modem or DSL modem.
3. DC power connector. Connect the power adapter that came in the product package
to the DC power connector.
4. Power On/Off button. Press the Power On/Off button to provide power to the
router.
5. Reset button. Pressing the Reset button resets the router.
If the Reset button is pressed for at least 10 seconds, the Power LED blinks amber
and the router resets its factory default settings. When the router finishes resetting
its factory default settings, the Power LED lights solid white.
6. USB 3.0 port. Use the USB 3.0 port to connect USB storage device.
Router label
The router label shows the login information, WiFi network name (SSID), password,
serial number, and MAC address.
Figure 4. Router label
User Manual12Hardware Setup
Nighthawk AX2400 WiFi 6 Router
