5-WORKINGOPERATIONS
Boomoperation
•
Movetheleverforwardtolowertheboom.
•
Movetheleverbackwardtoraisetheboom.
•
Movethelevertothelefttoswingtheboomtotheleft.
•
Movethelevertotherighttoswingtheboomtothe
right.
•
Swingleftandlowertheboombymovingtheleverfor-
wardandtotheleft.
•
Swingleftandraisetheboombymovingtheleverback-
wardandtotheleft.
•
Swingrightandlowertheboombymovingthelever
forwardandtotheright.
•
Swingrightandraisetheboombymovingthelever
backwardandtotheright.
NHIL17CT01829AA1
Dipperandbucketoperation
•
Movetheleverforwardtomovethedipperstickforward.
•
Movetheleverbackwardtomovethedipperstickback-
ward.
•
Movetherodtothelefttopullthebucketin.
•
Movetherodtotherighttoextendthebucketout.
•
Bymovingthelevertooneofthemiddlepositions,
thedipperstickcanbeextendedorretracted,whilethe
bucketislledoremptied.
•
Extendandllthebucketbymovingtheleverforward
andtotheleft.
•
Retractandllthebucketbymovingtheleverbackward
andtotheleft.
•
Extendandemptythebucketbymovingtheleverfor-
wardandtotheright.
•
Retractandemptythebucketbymovingtheleverback-
wardandtotheright.
•
Thetwofunctionsfortheboominthecombinationwith
thetwofunctionsforthebucketandthedipperstickoffer
foursimultaneouslywaysofworking.Theoilowworks
inawaythatrequirestheleastamountofpressure.
•
NHIL17CT01830AA1
Usingthestabilizers
WARNING
Unexpectedmachinemovement!
Beforeyouusethebackhoeattachment,makesurethatthemachineisrestingonthestabilizers.
Failuretocomplycouldresultindeathorseriousinjury.
W1326A
5-2
