5-WORKINGOPERATIONS
WARNING
Tip-overhazard!
Donotdigthegroundunderthebackhoestabilizers.Themachinecanfallintotheexcavationsiteif
theembankmentcollapses.
Failuretocomplycouldresultindeathorseriousinjury.
W0198A
Thestabilizers(1)areintendedtotakethepressureoffthe
rearwheelsofthetractor.Therearwheelsshouldtouch
thegroundbecausetheyhavethelowestcenterofgravity
andgivethestabilizersthewidestposition.
Raisedrearwheelsprovidelessstabilityandlessreach
forthebackhoe.Inaddition,itputsanunnecessarybur-
denonthetractorandbackhoe.
NHIL17CT01776AA1
Leftstabilizer
•
Moveleftlever(2)forward,leftstabilizerdrops.
•
Moveleftlever(2)backward,leftstabilizerraises.
Rightstabilizer
•
Moverightlever(1)forward,rightstabilizerdrops.
•
Moverightlever(1)backward,rightstabilizerdrops.
NHIL17CT00550AA2
Usingthebackhoe
DANGER
Avoidinjury!
Keepclearoftheswingarea.Ensurethatanypersonneartheworkingsiteisoutsidetheswingarea
beforeyoustartoroperatethemachine.Soundthehornbeforeyoustartoroperatethemachine.
Failuretocomplywillresultindeathorseriousinjury.
D0123A
WARNING
Electrocutionhazard!
Bealertforoverheadelectricallines.Proceedcautiouslyunderelectricallinesandaroundutility
poles.Electrocutioncanoccurwithoutdirectcontactwithoverheadelectricallines.
Failuretocomplycouldresultindeathorseriousinjury.
W1292A
5-3
