2
-
SAFETY
INFORMA
TION
Hand
signals
When
operating
the
machine,
always
work
with
a
signalman
when
you
carry
out
tasks
that
require
ne
control
and/or
require
you
to
work
in
areas
with
poor
or
impaired
visibility
.
Make
sure
that
you
and
the
signalman
understand
the
signals
to
be
used.
Start
the
engine
PDE0002A
TBP1
1
Shut
down
the
engine
PDE0002TBP1
2
Come
to
me
W
ave
hands
back
and
forth
(palms
inwards).
PDE0003A
TBP1
3
Move
away
from
me
W
ave
hands
back
and
forth
(palms
outwards).
PDE0003TBP1
4
Go
this
far
PDE0004A
TBP1
5
All
stop
and
hold
PDE0004TBP1
6
2-13
32
34
