point offset
SRLQW RIIVHW
FKDQJH LQ FXUYH
RXWGRRU WHPS SRLQW
r&
r&
RXWGRRU WHPS r&
IORZ WHPSHUDWXUH r&
outdoor temp. point
Setting range: -40 – 30 °C
Default value: 0 °C
change in curve
Setting range: -10 – 10 °C
Default value: 0 °C
Menu
1.9.8
Select a change in the heating curve at a certain outdoor temperature here.
A one degree change in room temperature requires one increment for under-
floor heating and approximately two to three increments for the radiator
system.
The heat curve is affected at ± 5 °C from set outdoor temp. point.
It is important that the correct heating curve is selected so that the room
temperature is experienced as even.
TIP
If it is cold in the house, at, for example -2 °C, "outdoor temp. point" is set
to "-2" and "change in curve" is increased until the desired room temperat-
ure is maintained.
NIBE™ F470Chapter 3 | F470 – at your service48
