alt and inversion Operating mode set in factory. When the control unit receives the command, it stops the Closing manoeuvre in
progress and activates a total inversion (Open). Caution! – During execution of the Opening manoeuvre, this com-
mand is ignored.
Detect obstacle in opening
In this command category the user can select one of the operating modes specied in Table 1-N.
TABLE 1-N: COMMAND CONFIGURATION
MODE DESCRIPTION
Stop Operating mode set in factory. When this type of function is set, when the control unit receives the command, it
stops the Opening manoeuvre in progress immediately.
Stop and brief inversion When the control unit receives the command, it stops the Opening manoeuvre in progress immediately and acti-
vates the application to perform a brief inversion in the opposite direction (Closing).
alt and inversion Operating mode set in factory. When the control unit receives the command, it stops the Opening manoeuvre in
progress and activates a total inversion (Closing). Caution! – During execution of the Opening manoeuvre, this com-
mand is ignored.
Detect obstacle in closing
In this command category the user can select one of the operating modes specied in Table 1-O.
TABLE 1-O: COMMAND CONFIGURATION
MODE DESCRIPTION
Stop Operating mode set in factory. When the control unit receives the command, it stops the Closing manoeuvre in
progress.
Stop and brief inversion When the control unit receives the command, it stops the Closing manoeuvre in progress immediately and activates
the application to perform a brief inversion in the opposite direction (Opening).
alt and inversion Operating mode set in factory. When the control unit receives the command, it stops the Closing manoeuvre in
progress and activates a total inversion (Open). Caution! – During execution of the Opening manoeuvre, this com-
mand is ignored.
OUTPUT CONFIGURATION
This item covers the functions available and associable with Outputs 1 (ash) - 2 - 3 present on the control unit of an automation. Each output has various
functions as described in a table (Table 2, Table 3, etc.):
OUTPUT
Trafc Light output for connection of the XBA7 or XBA8 internal asher.
TABLE 2: OUTPUT CONFIGURATION
FUNCTION DESCRIPTION
sca (0x01) The programmed light indicates the operating status of the control unit.
light off = application in maximum Closing position;
slow ashing = application Opening manoeuvre execution phase;
quick ashing = application Closing manoeuvre execution phase;
light permanently on = application in maximum Opening position.
SCA1 (0x14) The programmed light indicates the operating status of the control unit.
light permanently on = application in maximum Opening or maximum Closing position;
slow ashing = application Opening manoeuvre execution phase;
quick ashing = application Closing manoeuvre execution phase;
light off = application stationary, in a different position than maximum Closing or maximum Opening.
SCA2 (0x15) The programmed light indicates the operating status of the control unit.
light permanently on = application in maximum Closing position;
slow ashing = application Opening manoeuvre execution phase;
quick ashing = application Closing manoeuvre execution phase;
light off = application stopped in maximum Opening position.
Gate open (0x02) The programmed light indicates the operating status of the control unit.
light on = application in maximum Opening position;
light off = application in other positions.
Gate closed (0x03) The programmed light indicates the operating status of the control unit.
light on = application in maximum Closing position;
light off = application in other positions.
Flasher (0x05) This function enables the asher to indicate execution of a manoeuvre in progress with ashes at regular intervals
(0,5 sec. ON; 0,5 sec. OFF).
Flasher 1 (0x13) This function enables the asher to ash constantly at regular intervals (0.5 sec ON; 0,5 sec. OFF) both during a
manoeuvre and when the pole is stationary.
Courtesy light (0x06) This function turns the indicator on during the manoeuvre for the time set in the “Courtesy light time” parameter. The
function can also be activated in “ON/OFF” mode.
Always on (0x16) This function enables the indicator light to remain constantly lit both during a manoeuvre and when the pole is
stationary.
Red trafc light (0x0d) This function indicates the activity of the application during a closing manoeuvre: slow ashing = closing in progress;
light permanently on = application in maximum Closing position;
light off = application in other positions.
