Nice UST1K-1.1kW User Manual

GB
English – 17
Electronic board UST1K-1.1kW
Coupling terminal
control devices
Radio coupling
Limit switch
coupling terminal
Coupling terminal safety
elements contacts
with zero potential
PE screw terminal
OPENING
setting button
CLOSING
setting button
Key switch
connection
Triple button connection
Brake relay
connection
Antenna screw
terminal
Coupling terminal
of photoelectric
barrier passage
Plug connection
for assistance LED
T2 setting
button
DIP switch
Display
Red traffic
lights
Button T1
manual transmitter
setting
Network coupling
terminal
Motor coupling
terminal
Coupling terminal
of contact barrier
+ door half height
S2 rotary selector
J2 U-bolt

Nice UST1K-1.1kW Specifications

General

Brand	Nice
Model	UST1K-1.1kW
Category	Controller
Language	English
