Page #300 background imageLoading...
Page #300 background image
176
n
Storage
If the camera will not be used for an extended period, remove
the battery and store it in a cool, dry area with the terminal cover
in place. To prevent mold or mildew, store the camera in a dry,
well-ventilated area. Do not store your camera with naphtha or
camphor moth balls or in locations that:
are poorly ventilated or subject to humidities of over 60%
are next to equipment that produces strong electromagnetic
fields, such as televisions or radios
are exposed to temperatures above 50 °C (122 °F) or below –10 °C
(14 °F)
Cleaning
Do not use alcohol, thinner, or other volatile chemicals.
Storage and Cleaning
Camera body
Use a blower to remove dust and lint, then wipe gently with
a soft, dry cloth. After using the camera at the beach or sea-
side, wipe off sand or salt with a cloth lightly dampened in
distilled water and dry thoroughly. Important: Dust or other
foreign matter inside the camera may cause damage not cov-
ered under warranty.
Lens,
viewfinder
These elements are easily damaged. Remove dust and lint
with a blower. If using an aerosol blower, keep the can ver-
tical to prevent the discharge of liquid. To remove finger-
prints and other stains, apply a small amount of lens cleaner
to a soft cloth and clean with care.
Monitor
Remove dust and lint with a blower. When removing finger-
prints and other stains, wipe the surface lightly with a soft
cloth or chamois leather. Do not apply pressure, as this
could result in damage or malfunction.

Table of Contents

Other manuals for Nikon 1 v2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nikon 1 v2 and is the answer not in the manual?

Nikon 1 v2 Specifications

General IconGeneral
Megapixel14.2 MP
Camera typeMILC
Sensor typeCMOS
Sensor formatCX
Image stabilizerNo
Total megapixels15.13 MP
Image sensor size- \
Image formats supportedJPG, RAW
Supported aspect ratios3:2, 16:9
Maximum image resolution4608 x 3072 pixels
Image sensor size (W x H)13.2 x 8.8 mm
Still image resolution(s)3:2:\\r 4608 x 3072\\r 3456 x 2304\\r 2304 x 1536
Optical zoom- x
Focal length range- mm
Lens mount interfaceNikon 1
Minimum aperture number-
Focus adjustmentAuto/Manual
Auto Focus (AF) lockYes
Auto focusing (AF) modesContinuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Matrix, Spot
ISO sensitivity160, 6400
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)6400
ISO sensitivity (min)160
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed30 s
Flash modesFill-in, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed1/250 s
Flash guide number5 m
Flash exposure correction-3EV - +1EV (1/3 EV step)
Power source typeBattery
Video formats supportedH.264, MOV, MPEG4
Maximum video resolution1920 x 1080 pixels
Resolution at capture speed640x240@400fps
Audio formats supportedAAC
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution (numeric)921000 pixels
Viewfinder typeElectronic
Viewfinder screen size0.47 \
USB version2.0
HDMI connector typeMini
Data networkNot supported
Eye relief18 mm
Scene modesClose-up (macro), Night landscape, Portrait, Landscape (scenery)
Photo effectsBlack&White, Neutral, Vivid
White balanceAuto, Cloudy, Flash, Fluorescent, Incandescent, Shade, Sunny
Shooting modesAperture priority, Auto, Manual, Program, Shutter priority
Self-timer delay2, 10 s
Languages supportMulti
Camera file systemDCF, DPOF, Exif 2.3
Diopter adjustment (D-D)-3 - 2
Battery typeEN-EL21
Battery life (CIPA standard)310 shots
Product colorWhite
Operating temperature (T-T)0 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth45.9 mm
Width107.8 mm
Height81.6 mm
Weight278 g
Weight (including battery)337 g
