192
n
This section lists the error messages that appear in the display.
Error Messages
Message Solution 0
(Shutter-speed or
aperture display
flashes)
If the subject is too bright, lower ISO
sensitivity or choose a faster shutter
speed or smaller aperture (higher
f-number).
35, 36,
37, 135
If the subject is too dark, raise ISO sen-
sitivity, use a flash, or choose a slower
shutter speed or larger aperture (lower
f-number).
35, 36,
37, 69,
72, 135
Keeping the zoom ring
button pressed, rotate
the zoom ring to
extend the lens.
A lens with a retractable lens barrel
button is attached with the lens barrel
retracted. Press the retractable lens
barrel button and rotate the zoom ring
to extend the lens.
17, 202
Check lens. Pictures
can only be taken
when a lens is
attached.
Attach a lens. 17
Cannot take pictures.
Insert fully-charged
battery.
Turn the camera off and recharge the
battery or insert a fully charged spare
battery.
12, 14
Start-up error. Turn the
camera off and then
on again.
Turn the camera off, remove and
replace the battery, and then turn the
camera on.
14, 18
The clock has been
reset.
Set the camera clock. 19, 165
No memory card.
Turn the camera off and confirm that
the card is correctly inserted.
14
This memory card is
not formatted. Format
the memory card?
Select Ye s to format the card, or turn
the camera off and insert another
memory card.
14, 161
Memory card is locked
(write protected).
Turn the camera off and slide the card
write-protect switch to the “write
position.
15

Table of Contents

Other manuals for Nikon 1 v2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nikon 1 v2 and is the answer not in the manual?

Nikon 1 v2 Specifications

General IconGeneral
Megapixel14.2 MP
Camera typeMILC
Sensor typeCMOS
Sensor formatCX
Image stabilizerNo
Total megapixels15.13 MP
Image sensor size- \
Image formats supportedJPG, RAW
Supported aspect ratios3:2, 16:9
Maximum image resolution4608 x 3072 pixels
Image sensor size (W x H)13.2 x 8.8 mm
Still image resolution(s)3:2:\\r 4608 x 3072\\r 3456 x 2304\\r 2304 x 1536
Optical zoom- x
Focal length range- mm
Lens mount interfaceNikon 1
Minimum aperture number-
Focus adjustmentAuto/Manual
Auto Focus (AF) lockYes
Auto focusing (AF) modesContinuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Matrix, Spot
ISO sensitivity160, 6400
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)6400
ISO sensitivity (min)160
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed30 s
Flash modesFill-in, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed1/250 s
Flash guide number5 m
Flash exposure correction-3EV - +1EV (1/3 EV step)
Power source typeBattery
Video formats supportedH.264, MOV, MPEG4
Maximum video resolution1920 x 1080 pixels
Resolution at capture speed640x240@400fps
Audio formats supportedAAC
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution (numeric)921000 pixels
Viewfinder typeElectronic
Viewfinder screen size0.47 \
USB version2.0
HDMI connector typeMini
Data networkNot supported
Eye relief18 mm
Scene modesClose-up (macro), Night landscape, Portrait, Landscape (scenery)
Photo effectsBlack&White, Neutral, Vivid
White balanceAuto, Cloudy, Flash, Fluorescent, Incandescent, Shade, Sunny
Shooting modesAperture priority, Auto, Manual, Program, Shutter priority
Self-timer delay2, 10 s
Languages supportMulti
Camera file systemDCF, DPOF, Exif 2.3
Diopter adjustment (D-D)-3 - 2
Battery typeEN-EL21
Battery life (CIPA standard)310 shots
Product colorWhite
Operating temperature (T-T)0 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth45.9 mm
Width107.8 mm
Height81.6 mm
Weight278 g
Weight (including battery)337 g
