Nikon 1 v2 User Manual

189
n
Shooting (All Modes)
The camera takes time to turn on: Delete files or format the memory card.
The shutter-release is disabled:
• The battery is exhausted (0 12, 21).
• The memory card is locked (0 15) or full (0 21).
• The flash is charging (0 69).
• The camera is not in focus (0 24).
• You are currently filming a slow motion movie (0 51).
Only one picture is taken each time the shutter-release button is pressed in continuous
release mode: 5 fps is selected for Continuous and the built-in flash is
raised.
The camera does not focus automatically:
• The subject is not suited to autofocus (0 150).
• The camera is in manual focus mode (0 149, 151).
Focus does not lock when the shutter-release button is pressed halfway: Use the 1
(A) button to lock focus when AF-C is selected for focus mode or when
photographing moving subjects in AF-A mode (0 149, 154).
Focus area selection is unavailable: Focus area selection is not available in
auto-area AF (0 153) or face priority (0 27). In other AF-area modes, the
focus area can be selected by pressing J.
Subject-tracking AF not available: Select a non-monochrome Picture Control
(0 136, 153).
AF-area mode selection is unavailable: The camera is in auto or best moment
capture mode (0 41), manual focus mode is selected (0 149), or the h
Scene auto selector is used (0 122).
Image size selection is unavailable: NEF (RAW) is selected for image quality
(0 123).
The camera is slow to record photos: Turn long exposure noise reduction off
(0 146).
Noise (bright spots, randomly-spaced bright pixels, fog, or lines) appears in photos:
• Lower ISO sensitivity or enable high ISO noise reduction (0
146).
• Use long exposure noise reduction at shutter speeds slower than 1 s
(0 146).
No photo taken when ML-L3 remote control shutter-release button is pressed:
• Replace battery in remote control (0 170).
• Choose a remote control mode (0 63).
• The remote control standby timer has expired (0 163).
• The remote is not pointed at the camera or the infrared receiver is not
visible (0 2, 66).
• The remote is too far from the camera (0 66).
• Bright light is interfering with remote.

Nikon 1 v2 Specifications

General

Megapixel	14.2 MP
Camera type	MILC
Sensor type	CMOS
Sensor format	CX
Image stabilizer	No
Total megapixels	15.13 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2, 16:9
Maximum image resolution	4608 x 3072 pixels
Image sensor size (W x H)	13.2 x 8.8 mm
Still image resolution(s)	3:2:\\r 4608 x 3072\\r 3456 x 2304\\r 2304 x 1536
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon 1
Minimum aperture number	-
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Matrix, Spot
ISO sensitivity	160, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	160
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	30 s
Flash modes	Fill-in, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed	1/250 s
Flash guide number	5 m
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	640x240@400fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.47 \
USB version	2.0
HDMI connector type	Mini
Data network	Not supported
Eye relief	18 mm
Scene modes	Close-up (macro), Night landscape, Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Program, Shutter priority
Self-timer delay	2, 10 s
Languages support	Multi
Camera file system	DCF, DPOF, Exif 2.3
Diopter adjustment (D-D)	-3 - 2
Battery type	EN-EL21
Battery life (CIPA standard)	310 shots
Product color	White
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	45.9 mm
Width	107.8 mm
Height	81.6 mm
Weight	278 g
Weight (including battery)	337 g
