Nikon COOLPIX S4 User Manual

6
First Steps
First Steps
Inserting the Batteries
The camera uses two AA batteries. Depending on the country or region of
purchase, the package will include either alkaline batteries or an MH-71 bat-
tery charger with rechargeable EN-MH1-B2 batteries.
1
Charge the batteries (EN-MH1-B2 batteries only)
If the camera came with a battery charger and rechargeable Nikon EN-MH1-B2
NiMH batteries, charge the batteries as described below. If the camera came
with a pair of alkaline batteries, skip to Step 2 on the following page.
Batteries
Read and follow the warnings and cautions on pages ii–iii and 84 of this
manual. The camera can be used with AA alkaline (LR6) batteries, Nikon rechargeable
EN-MH1-B2 NiMH batteries, ZR6 oxy-nickel batteries, and FR6/L91 lithium batteries. Do
not mix old and new batteries or batteries of different makes or types. Batteries
with the following defects can not be used:
EN-MH1-B2 Batteries
Charge EN-MH1-B2 batteries before fi rst use. Charge and use as a set: do not charge
batteries one at a time or mix batteries from different pairs. Note that the batteries may
tend to discharge more quickly when new or after a long period of disuse. The batter-
ies will retain a charge longer once they have been used and recharged several times.
“Memory” effects that result in reduced battery capacity can be avoided by periodically
refreshing the batteries as described in the Appendix ( 93).
Peeling or
damaged
insulation
Insulation does
not reach nega-
tive terminal
Flat
negative
terminal
1.1 Plug the charger in
Connect the power cable to the charger (햲)
and then plug it into a power outlet (햳). The
CHARGE lamp will light (햴).
1.2 Charge the batteries
Insert the batteries as indicated on the charger.
The CHARGE lamp will start to blink. Charging
is complete when the lamp stops blinking.
A pair of new or fully exhausted batteries will
charge in about two and a half hours.
햲
햲
햳
햳
햴
햴

Nikon COOLPIX S4 Specifications

Camera Specifications

effective pixels	6.0 million
ccd	1/2.5-inch type (6.4 million total pixels)
lens	10x Zoom-Nikkor; 6.3-63.3mm (35mm [135] format equivalent to 38-380mm); f/3.5; 12 elements in 9 groups; Digital zoom: up to 4x (35mm [135] format equivalent to 1520mm)
focus range	12 in.(30cm) to infinity (∞), approx. 2.5 in (4cm) to infinity (∞) in Macro mode
lcd monitor	2.5-inch type, 110, 000-dot Amorphous silicon TFT LCD monitor with brightness adjustment

Image Modes

image mode high	2816 x 2112
image mode economy	2048 x 1536
image mode pc screen	1024 x 768

Battery and Power

power requirements	2x AA-size(LR6) batteries (Alkaline [supplied] or EN-MH1-B2 with MH-71 [optional]), EH-62B AC adapter kit
battery life with rechargeable batteries	Approx. 290 images
battery life with alkaline batteries	Approx. 160 images
battery life with lithium batteries	Approx. 450 shots

Storage and Memory

internal memory	approx. 13.5MB
storage media	SD memory card
number of frames with internal memory	6M: High (2816*) approx. 4, Normal (2816) approx. 9

Weight and Dimensions

dimensions	4.4 x 2.7 x 1.4 in. (111.5 x 68.5 x 37mm)
weight	7.2 oz. (205g)
