Specifications
COOLSHOT 20i GIII COOLSHOT 20 GIII
Measurement range
(actual distance)
5-730 m/6-800 yd.
Distance display
(increment)
1 m/yd.
Accuracy (actual
distance)
*1
±1 m/yd. (shorter than 100 m/yd.)
±2 m/yd. (100 m/yd. and over)
Magnification (×) 6
Effective diameter of
objective lens (mm)
20
Angular field of view
(real) (˚)
6.0
Eye relief (mm) 16.7
Exit pupil (mm) 3.3
Diopter adjustment ±4 m
-1
Dimensions (L × H ×
W) (mm/in.)
91 × 73 × 37/3.6 × 2.9 × 1.5
Weight (g/oz.) Approx. 130/4.6 (without battery)
Operating
temperature (˚C/˚F)
-10 — +50/14 — 122
Operating humidity
(%RH)
80 or less (without dew condensation)
Power source
CR2 lithium battery × 1 (DC 3V)
Automatic power shut-off (after approx. 8 sec.
unoperated)
Structure Rainproof
*2
Electromagnetic
compatibility
FCC Part15 SubPartB class B, EU:EMC directive, AS/
NZS, VCCI classB, CU TR 020, ICES-003,
GB: Electromagnetic Compatibility Regulations
Environment RoHS, WEEE
Laser classification
IEC60825-1: Class 1M/Laser Product
FDA/21 CFR Part 1040.10: Class I Laser Product
Wavelength (nm) 905
Pulse duration (ns) 20
Output (W) 15.2
Beam divergence
(mrad)
Vertical: 2.5, Horizontal: 0.2
• The specifications of the product may not be achieved depending on the target
object’s shape, surface texture and nature, and/or weather conditions.
Technical notes
