SPECIFICATIONS
WIRING REQUIREMENTS
Keypad to Niles MultiZone Control System
Up to 500 feet of individually home-run four pair twisted cable (CAT3 or CAT5)
IR Sensor to Master Keypad
Up to 500 feet of individually home-run four pair twisted cable (CAT3 or CAT 5). Or, up to
500 feet of individually home-run 22 gauge two-conductor, shielded cable (West Penn D291
or equivalent).
NOTE: A Niles Adapter (FG00852) is required to connect an IR Sensor when using two
conductor shielded cable.
FCC CERTIFICATION
Class “B” certified for use in residential environments.
MOUNTING
In-wall mounting Decora-style modules, fit into electrical boxes at least 2-1-2" deep.
UNIT DIMENSIONS
Model Height Width Depth
Solo 4" 1-3/4" 1-5/8"
Select 4" 1-3/4"
1-5/8”
Numeric 4" 1-3/4" 1-1/8"
Transport 4" 1-3/4" 1-1/8"
I
NTELLI
P
AD
®
C
I
K
EYPAD
M
ODULES
16
