Solo Master Keypad Module
The Solo (See Figure 1) is one of two Master Keypad Modules available. It was designed to
operate alone, or in conjunction with a Numeric Accessory Keypad Module (See
Figure 3). The four Master Keys on the Solo provide the end user with customized control of
up to four audio/video components or “sources”. These Master Keys can be programmed to
initiate a sequence of customized commands.
Select Master Keypad Module
The Select (see Figure 2) is one of two Master Keypad Modules available. It was designed to
operate alone, or in conjunction with the Numeric Accessory Keypad Module, the Transport
Accessory Keypad Module or both. It provides the end-user with sophisticated control for
sources via its eight master keys.
Numeric Accessory Keypad Module
The Numeric (see Figur
e 3
and Figur
e 4
) is one of two Accessor
y Keypad Modules. It cannot
be used without a Master Keypad Module. It operates in conjunction with either the Solo or
Select Master Keypad Modules, giving the end user direct access when operating a DSS,
CD/DVD Changer, AM/FM Tuner or any other component that requires a numeric address. Its
keys change their function each time a new (Master Key) is selected.
Transport Accessory Keypad Module
The Transport (see Figure 4) is one of two Accessory Keypad Modules available. It cannot be
used without a Master Keypad Module. It operates in conjunction with the Select Master
Keypad Module, giving the end user advanced control for transport functions. Its keys change
their function each time a new source (Master Key) is selected.
I
NTELLI
P
AD
®
C
I
K
EYPAD
M
ODULES
3
