BEFORE MACHINE START-UP
WARNING!
When starting the machine, or before operating the One-Touch™ push-button (43), make sure that there is
no foreign material between the deck and the tank assembly which could obstruct the deck movement. If the
machine has been turned off without lifting the deck, the deck would lift automatically at next machine start-up.
Brush or pad-holder removal/installation
1. According to the kind of cleaning to be performed, the
machine can be equipped either with the brush (A, Fig.
2) or the pad-holder (B) with pad (C) together with the
appropriate deck.
2. Place the brush (A) or the pad-holder (B) under the deck
(7).
3. Insert the operator key (41) in its slot.
4. Press the One-Touch™ button (43) to lower the deck onto
the brush.
5. Press the switch (45) to engage the brush.
6. To remove the brush, the deck must be lifted by pressing
the push-button (43), then press the release push-button
(45).
7. When the display shows the icon (51-K), wait for the brush
to fall on the oor.
B
A
C
Figure 2
P100864
Available brushes and their relevant application guides (suggestions only)
Models 46 GRIT 80 GRIT 180 GRIT 240 GRIT 500 GRIT PROLENE PROLITE UNION MIX
General cleaning:
Concrete
Terrazzo oor
Ceramic tiles/quarrystones
Marble
Vinyl tiles
Rubber tiles
Polishing:
Rubber tiles
Marble
Vinyl tiles
