Nilfisk-ALTO MC 3C Service Manual

B
Technical data
SM MC 3C_ MC 4M Ver.1.0_March 2015
5
Parentitemno: Descripon:
107146377 MC3C‐130/660220/1/60/15EXPT
Service data Unit Value
Model
MC 3C-130/660
Item no.
107146377
TECHNICAL DATA
PUMP:
Pressure pump head @ Qiec bar
132
Pressure pump outlet @ Qiec bar
130
Pressure gun outlet @ Qiec bar
111
Retaining pressure* bar
164
Flow. Qiec l/min
9,2
Suction height dry m
0,5
Suction height primed m
1
Pump type
NA3
Number of pistons
3
Piston type
Stainless Steel
Stroke mm
0
Pump oil type
SAE 80W-90 API GL-5
Pump oil amount L
0,42
ELECTRIC:
Electric data
Highvoltage (HV) test voltage kV
1,5
HV Insulation resistance
1
Earth circuit resistance
0,2
Pump revolutions
3460
Electrical diagram no.
0
UNIT DATA:
Nozzle size, water
NT 0400
Max. Inlet temp. (primed) °C
25 (50 max.1 hour)
Max. Inlet temp. (suction) °C
25 (50 max.1 hour)
Max. Inlet temp. (pressure fed) °C
60 (>40°C max. 1h)
Gun Type
ERGO 2000 STANDARD GUN W/O HOSE SWIVEL
Primary Lance Type
FLEXOPOWER PLUS 990 BEND W/O NOZZLE BLUE
Secondary Lance Type
None
Hose
DN6 x 10m
Guarantied sound power
91
Impactfactor calculated
2,8
Vibration ISO 5349, lance 1 / lance 2
<1,5; +/-1
Protection Class
IPX5
Machine incl. standard acc. kg
36
Size - Machine alone L x W x H mm
382x382x1017
