Nilfisk-ALTO MC 4M Service Manual

F
SM MC 3C_ MC 4M Ver.1.0_March 2015
Service / Repair
61
E-Box disasassembly
Remove two screws (Torx 20) in the top of
the backside cabinet.
MC 3C 4M
Remove the 2 screws (Torx 20) from the E-
box front cover
Lift up and pull off the E-box cover E-box cover removed
Lift up and pull out the E-box. The E-box can be fixed (see red arrows) to
the motor cover during service.
