FRONT VIEW
LEFT SIDE VIEW
RIGHT SIDE VIEW
REAR VIEW
TOP VIEW
4.62
68.25
3.50
69.00
72.00
76.25
32.44
AIR TREATMENT
CONTROL SYSTEM
A
DETAIL A
1.00
TYP
70.00
1.25
TYP
28.75
O .50 MTG HOLES
(4 PLCS)
7.12
10.62
9.00
59.88
9.00 16.00
4"-300# R.F.S.O. FLANGE
AIR INLET CONNECTION
4"-300# R.F.S.O. FLANGE
AIR OUTLET CONNECTION
1'' FPT WATER OUTLET
CONNECTION
1'' MPT WATER INLET
CONNECTION
1/2" FPT CONNECTION
NO AIR LOSS DRAIN
(SEE DETAIL)
LCD DISPLAY
1) CHILLER TEMP
2) COMPRESSOR ON/OFF
3) DRAIN INTERVAL
4) DRAIN ON
5) PERCENT SAVINGS
6) CUMULATIVE DRYER HOURS
7) CUMULATIVE COMPRESSOR HOURS
8) CUSTOMER SET POINTS
PUSHBUTTONS
1) ON
2) OFF
3) RESET
4) TEST
5) SET
6) SELECT DISPLAY
7) ENTER
8) +/-
CONDENSER AIR
DISCHARGE
CONDENSER AIR
INLET
CONDENSER AIR
DISCHARGE
CONDENSER AIR
DISCHARGE
CONDENSER AIR
INLET
CONDENSER AIR
INLET
5.44
5.75
NO AIR LOSS DRAIN ASSEMBLY DETAIL
DRAIN SHUT-OFF
VALVE
1/8'' NPT OPERATING
AIR PRESSURE PORT
(CUSTOMER SUPPLIED
80 - 120 PSIG)
NO AIR LOSS DRAIN ASSEMBLY
(FACTORY INSTALLED)
(PANELS NOT SHOWN FOR CLARITY)
GENERAL ARRANGEMENT
D4290NCHP
AIR AND WATERCOOLED, NEMA-1
550107
