14.0 REPLACEMENT PARTS
DESCRIPTION D4290NCHPW400 D5635NCHPW400 D7055NCHPW400
QTY /
UNIT
SPARES
1 2 3
CABLE, TRANSDUCER - 10 FT LEAD 682946 682946 682946 2
COMPRESSOR, REFRIGERATION 682248 682346 682346 1 1 1 1
CONDENSER, REFRIGERANT 698202 683596 683596 1
CONTACTOR, COMPRESSOR 698343 698343 698343 1 1 1 1
DISTRIBUTOR, REFRIGERANT 683876 683413 683413 1
DRAIN VALVE, AIRLESS 22758643 22758643 22758643
DRYER CONTROLLER, TYPE 4 WITH
REFRIGERATED PROGRAM, (Dryer
model and serial number must
be provided with order to ensure
proper conguration.)
800029 800029 800029 1 1 1 1
DRYER, REFRIGERANT FILTER 600388 600388 600388 1
FUSE, GLYCOL PUMP 682646 682646 682646 1 1 1 2
FUSE, TRANSFORMER PRIMARY 682651 682651 682651 2 2 2 4
FUSE, TRANSFORMER SECONDARY 698770 698770 698770 1 1 1 2
HEATER, COMPRESSOR
CRANKCASE
682245 682245 682245 1
POWER SUPPLY - 24V DC 683956-SP 683956-SP 683956-SP 1 1 1 1
PROBE, EXCHANGER/SUCTION
TEMPERATURE
682955C 682955C 682955C 2 1 1 1
PUMP, GLYCOL 683724 683724 683724 1 1 1 1
RELAY, PUMP 698262 698262 698262 1
RESISTOR, CONTROL PANEL
DUMMY LOAD
683968 683968 683968 1
TRANSDUCER, REFRIGERANT
DISCHARGE PRESSURE
682943 682943 682943 1 1 1 1
TRANSDUCER, REFRIGERANT
SUCTION PRESSURE
682942 682942 682942 1 1 1 1
TRANSFORMER, CONTROL - 0.25
KVA
699640 699640 699640 1
VALVE, GLYCOL PUMP ISOLATION 684061 684061 684061 2 1
VALVE, REFRIGERANT EXPANSION 600401 683840 683840 1
VALVE, SOLENOID - REFRIGERANT
LIQUID LINE
683338 683338 683338 1
VALVE, WATER CONTROL 698204 680181 680181 1
AIR EXCHANGER ASSEMBLY (STD) - - - 1
AIR EXCHANGER ASSEMBLY (SS,
OPT)
- - - 1
Spare. Quantities under this heading reect the number of each item which we recommend be kept on hand for
maintenance or repair.
The appropriate quantity for your application will depend on how critical interruptions in service are to your operation.
Class Quantity Suggested for
1 Minimum Domestic service where interruptions in service are acceptable.
2 Average Domestic service where some interruptions in service are acceptable.
3 Maximum Export service or for domestic service where interruptions in service are unacceptable.
