Camera:
•
Parallel camera interface is natively supported by XG213
•
CSI-2 type interface with interface IC
Removable storage:
•
MMC/SD card
Accessories:
•
Support for Signature type accessories
•
Support for headset
•
TTY support
Production support:
•
Secure boot for flash image download
•
USB/Serial protocols for flashing
Chipset and key components
The following table lists all major components in the design on baseband side.
Table 3 Chipset key components
Part Number Function Reference Designator
X-GOLD 213 V2.1S Engine IC D3100
K5N1266ACM-BT80 32MX16 NOR /4MX16 PSRAM D3000
STSMIA832 De-serializer for Camera N3000
BC8810 Bluetooth module N6005
26MHz DCXO B7100
32.768KHz crystal B3000
RM-761; RM-799; RM-800
System Module
Page 5 – 6 COMPANY CONFIDENTIAL Issue 1
Copyright © 2011 Nokia. All rights reserved.
