Nokia 4G05-A User Manual

Functional overview Nokia FastMile 4G Receiver Product Overview
42 3TG-00386-ABAA-TCZZA Issue: 01 DRAFT
DRAFT
Figure 9 Remote management of the Nokia FastMile 4G Receiver through the Nokia
Altiplano FastMile Controller
Figure 10 shows an ACS being used for remote management of the Nokia FastMile
4G Receiver. Note that the ACS uses TR-069 to manage both the Nokia FastMile
4G Receiver and the residential gateway.
Radio
basestation
Nokia
Altiplano
Fastmile
Controller
NETCONF
TR-069
Residential
gateway
PoE
Injector
LTE
1
Gbps
Ethernet
Wi-Fi or
Ethernet
WiFi or Etherne
connectivity to
end-user devic
that are using
IPTV, internet,
and VoIp
28
Core
IPTV
Internet
VoIP
ACS
Nokia
FastMile
4
G Receiver
