Nokia FastMile 4G User Manual

Nokia FastMile 4G Receiver Product Overview Performance information
Issue: 01 DRAFT 3TG-00386-ABAA-TCZZA 57
DRAFT
• Downlink: DL 3xCA 2x2MIMO 256 QAM
• Uplink: single carrier 64 QAM
• FDD inter-band 3CA
• TDD Band 41 intra-Band 3CA, configuration is configuration 2, subframe 7
• Base Bandwidth 20M
• Data rates can have a margin of 2%
• Packet length is 1470B for UDP
• Window is 1000k for TCP
• Data rates are for IPv4 cases
• Data forwarding working on router model
The end-to-end throughput is achieved in the conductive mode with cable connected.
Ethernet throughput for the Nokia FastMile 4G Receiver is as per standard Ethernet
1000BASE-T, with a maximum of 1000 Mbps. The Ethernet link gets negotiated at
1000 Mbps when a residential gateway or a PoE injector is connected to the Nokia
FastMile 4G Receiver.
12.3 Carrier aggregation information
The following tables provide carrier aggregation support information for the Nokia
FastMile 4G Receiver:
• Compact mono-band and ABA models: Table 12
• Compact multi-band B3/B7/B20/B32 (Model 4G04-A): Table 13
• Compact multi-band B1/B3/B7/B38/B40/B41/B20/B28 (Model 4G05-A): Table 14
Table 12 Carrier aggregation support for the Compact mono-band and
ABA models
Band
Downlink
Carrier aggregation support
B42
3400 MHz-3600 MHz
Up to 40 MHz bandwidth contiguous 2CA
Up to 40 MHz bandwidth non-contiguous 2CA
Up to 60 MHz bandwidth contiguous 3CA
Up to 60 MHz bandwidth non-contiguous 3CA
B43
3600 MHz-3800 MHz
Up to 40 MHz bandwidth contiguous 2CA
Up to 40 MHz bandwidth non-contiguous 2CA
Up to 60 MHz bandwidth contiguous 3CA
Up to 60 MHz bandwidth non-contiguous 3CA
(1 of 2)

Nokia FastMile 4G Specifications

General

Technology	4G LTE
Maximum Download Speed	150 Mbps
Maximum Upload Speed	50 Mbps
Antenna Type	Internal
Frequency Bands	LTE Bands 1, 3, 7, 8, 20, 28, 38, 40
Power Supply	12V DC
Ethernet Ports	4 x RJ45
