Service Manual Level 1 and 2
Nokia Lumia 510
RM-889, RM-898
Version 1.0
Solder components
SK3702
Camera
switch
switch
SK3704
Volume -
switch
SK3703
Volume +
switch
BOTTOM
v1.0
NOKIA LUMIA 510
RM-889, RM-898
Solder components
©2012 Nokia | Confidential | All Rights Reserved.
