Nokia Lumia 510 Service Manual

Service Manual Level 1 and 2
Nokia Lumia 510
RM-889 RM-898
Version 1.0
Product controls and interfaces
1
2
3
4
6
5
11
12
13
15
7
8
9
14
10
14 — Battery cover release notch
15 — Loudspeaker
9 — Micro USB connector
8 — Microphone
7 — Search key
6 — Start key
5 — Back key
4 — Touch screen
3 — Proximity & Ambient light
sensor
2 — Earpiece
1 — Nokia AV 3.5 mm connector
10 — Camera
11 — Volume keys
12 — Lock/Power key
13 — Camera key
v1.0
©2012 Nokia | Nokia Internal Use only | All Rights Reserved.

Nokia Lumia 510 Specifications

General

Brand	Nokia
Model	Lumia 510
Category	Cell Phone
Language	English
