OBL PRO Series User Manual

File: UT-5601 Copyright © - OBL Metering pumps - All rights reserved
19
4 TECHNICAL DATA
The KIT PRO is suitable for all OBL’s metering pumps of the Black Line series with a standard
motor (three-phase power supply 230/380V 50 Hz). Contact an OBL distributor in the event motors
with different characteristics are installed.
Table 3- Technical data
M
R
Mechanical data
Max. flow rate (@ 1,5 bar)
800 lt/hr
1050 lt/hr
Max pressure
12 bar
40 bar
Max. stroke frequency
155 strokes/min
114 strokes/min
Max. suction lift
1,5 m
1,5 m
Liquid temperature
-10°C÷+40°C
-10°÷+90°C
Max. weight
28 Kg
26 Kg
Accuracy
+/- 3%
Linearity
+/- 5%
+/- 3%
Repeatability
+/- 3%
Turndown ratio
500:1
Sound pressure
70 dbA
Materials (actuator, casing, motor)
Aluminum
Finishing (actuator, casing)
Electrophoretic deposition (EPD)
Electrical data
Max power consumption
1500W
Max motor power
750W
Max output current
3,3 A on 1,9 A off (0,2 s ON 50%)
3A (100%)
Max input current
4.2 A
Power Supply
110 V AC
230 V AC
Frequency
50/60 Hz
Operating temperature
-10/40 °C 14/113 °F
Max inrush current
2,3A (110V)
5A (230V)
Enclosure class (actuator only)
IP65
Recommended fuse
6,3 x 32mm 8A
USB
Type
USB 2.0 HOST
Serial
MODBUS RTU
Half Duplex RS-485
Input
4-20 mA
Max input Voltage /Control input
14 V DC
Impedance
120 Ω
0-10 V
Input Voltage /Control input passive
10 V DC
Impedance
15 kΩ
Pulse (PNP)
Voltage Range High Level
Min 19V DC - Max 29 V DC
Max resistance in pulse circuit
15 KΩ
Min pulse length
10ms
Remote
Max load START/STOP digital input
28 V DC
Level
Max load STOP digital input
28 V DC
