9 Use of the BIOM® 5
18 / 36 Instruction Manual BIOM® 5 (G/55400/1218/en)
9.5 Swing the BIOM
®
5 to the Parked Position
 During extra-ocular surgery phases, swing the BIOM® 5 out of the
beam path into the parked position.
 When swinging out the BIOM, push in the safety rod, including the
front loupe, with you finger, until the rod reaches the limit stop.
☞
When swinging into the beam path:
 Lift up safety rod and only release it again when the swung-in end
position has been reached.
9.6 Make the Basic Settings at the Microscope
 Adjust the microscope to the anterior eye segment and perform the
surgery steps under microscope illumination, including starting the
infusion.
Fig. 9-7: BIOM® 5cl in the working position Fig. 9-8: BIOM® 5cl at parked position
