17 Technical Data
Instruction Manual BIOM® 5 (G/55400/1218/en) 33 / 36
17 Technical Data
Dimensions of the BIOM
®
5
Weight
Ambient Conditions, Transport and Storage Requirements for Optics
These values apply to all BIOM® versions.
BIOM® 5m and BIOM® 5c BIOM® 5ml and BIOM® 5cl
Dimensions (W x D x H) 63 x 112 x 110 –145 mm 63 x 112 x 124–160 mm
Total height approx. 123 –158 mm approx. 137–173 mm
Travel of safety rod approx. 29 mm approx. 29 mm
Product Weight Product Weight
BIOM® 5m
approx. 186 g BIOM® 5cl approx. 260 g
BIOM® 5ml
approx. 190 g Reduction lens approx. 30 g
BIOM® 5c
approx. 250 g Front loupe: depending on
the model
approx. 3 — 10 g
Operating conditions Transport requirements for
BIOM® 5c and BIOM® 5cl, in
acc. with DIN EN 60601-1
Storage requirements for
BIOM® 5c and BIOM® 5cl, in
acc. With DIN EN 60601-1
Temperature +10°C to +35°C -40°C to +70°C -10°C to +55°C
Humidity 30% to 70% 10% to 95% 10% to 95%
Air pressure 700 hPa to 1060 hPa 500 hPa to 1060 hPa 700 hPa to 1060 hPa
