Installing upgrades > 71
W
IRELESS
LAN
MODULE
The optional wireless LAN module to the machine allows you to use the wireless LAN
function.
1. Turn the machine off, and then unplug the power cord.
2. Press the cover release and open the printer’s output tray fully.
3. Pull down the MP Tray using the depressions. Lift the front cover release lever and
lower the front cover.
4. Loosen the screw (a) securing the right-hand side cover. Lift the edge of the side
cover slightly and pull the cover away from the printer at the top. Lift the cover
slightly to detach it from the printer. Place it safely to one side.
NOTE
Wait for at least 1 minute after unplugging the power cord, and then proceed
to the next step.
WARNING!
If the printer has been powered on recently, the fuser will be hot.
This area is clearly labelled. Do not touch.
a
To Next Page
