- 22 -
2. Setting Up
3
Eject the connector from the cover and connect with the wireless LAN module.
4
Install the wireless LAN module to the machine.
5
Close the wireless LAN module cover.
Go to "Connecting the Power Code”.
Attaching the wireless module cannot connect the machine to the wireless LAN.
Enable the wireless setting in the steps in "
Connecting to a Wireless LAN (Only When the Wireless LAN Module
is Mounted)
".
Attach the additional tray unit when increasing the number of sheets or paper to be set is
needed.
Up to 2 trays can be installed.
Set the number of trays on the printer driver after installing them.
1
Check that the machine is turned off and power cord and all the cables are
unplugged.
Installing the additional tray unit with the machine turned on may cause the machine and additional tray unit to
malfunction.
Installing the Additional Tray Unit
Model Number: N36501
Injury may result.
Lift this machine by 2 persons, because it weighs approximately 24 kg.
To Next Page
