Oki ML186 User Manual

31 • Setting Up Your Printer
Computer Connections
USB Connection
USB Cable Requirements
• USB 1.1 or higher
• Max. length 19.7 ft. (5 m)
• USB “B” series connector
Notes
• For connection to a PC running Windows
®
98 or
above, but not Windows 95 upgraded to Windows
98.
• The operation of a printer is not assured if a USB
compatible device is connected concurrently with
other USB-compatible machines.
• When connecting multiple printers of the same
type. they appear as *****, *****(2), *****(3), etc.
These numbers depend on the order of
connecting or turning on of each printer.
• USB is a “hot-pluggable” protocol. This means
that the printer and computer do not necessarily
have to be switched OFF.
• Interface cables are not supplied with your printer.

Oki ML186 Specifications

Technology and Print Characteristics

printhead	9-Pin SIDM
graphics resolution	240 (H) x 216 (V) dpi maximum
feed rate	2.0 ips
character pitch	10, 12, 15, 17.1 and 20 cpi
print speed	62.5 cps (NLQ), 250 cps (Utility), 333 cps (HS Draft), 375 cps (SS Draft)
matrix	12 x 17 (NLQ), 12 x 9 (Utility), 10 x 9 (HS Draft), 8 x 9 (SS Draft)

Emulation, Interface and Memory

co-resident emulations	IBM 2480, Epson ESC/P, OKI MICROLINE
interface	Integrated USB and IEEE Parallel, Optional RS-232C Serial, Ethernet via OkiLAN 6020e
memory	128K Receive Buffer

Paper Handling

paper input	Single-part, Multi-part, Continuous forms, Cut sheet, Card stock, Envelopes, Labels
number of copies	4-part Rear Feed, 5-part Bottom Feed
thickness	0.011" (0.28mm) maximum

Warranty and Reliability

limited warranty	3-Year parts and labor, 2-Year printhead
MTBF	20, 000 hours (25% duty cycle/35% page density)
monthly workload	13, 000 pages at 25% duty cycle/35% density
printhead life	200 million characters avg. in 10 cpi utility mode at 25% duty, 35% page density
ribbon life	3 million characters (Utility mode)

Environmental

size	14.65" x 10.83" x 3.15" (37.2 cm x 27.5 cm x 8.0 cm)
net weight	10 lb. (4.5 kg)
acoustic noise	58 dBA
