Serial Interface Parameters
Note: Defaults are underlined.
Switch Bank 1 Switch Bank 2
Parity Type
Odd Parity
Even Parity
Parity
No parity
With parity
Data Bits
8 bits
7 bits
Protocol
ReadyBusy
X-ON/X-OFF
Test Select
Circuit
Monitor
Mode Select
Print mode
Test mode
Busy Line
Selection
SSD- Pin 11
SSD+ Pin 11
DTR- Pin 20
RTS- Pin 4
Switch 1
ON
OFF
Switch 2
ON
OFF
Switch 3
ON
OFF
Switch 4
ON
OFF
Switch 5
ON
OFF
Switch 6
ON
OFF
Switches 7, 8
OFF, ON
OFF, OFF
ON, ON
ON, OFF
Transmission Speed
19,299 bps
9,600 bps
4,800 bps
2,400 bps
1,200 bps
600bps
300 bpc
110 bps
DSR Input Signal
Active
Inactive
Buffer Threshold
32 bytes
256 bytes
Busy Signal Timing
200 ms minimum
1 second minimum
DTR Signal
Space after power on
Space when printer
selected
Not Used
Switches 1, 2
ON, ON, ON
OFF, ON, ON
ON. OFF, ON
OFF, OFF, ON
ON, ON, OFF
OFF, ON, OFF
ON, OFF, OFF
OFF, OFF, OFF
Switch 4
ON
OFF
Switch 5
ON
OFF
Switch 6
ON
OFF
Switch 7
ON
OFF
Switch 8

Oki ML186 Specifications

Technology and Print Characteristics

printhead	9-Pin SIDM
graphics resolution	240 (H) x 216 (V) dpi maximum
feed rate	2.0 ips
character pitch	10, 12, 15, 17.1 and 20 cpi
print speed	62.5 cps (NLQ), 250 cps (Utility), 333 cps (HS Draft), 375 cps (SS Draft)
matrix	12 x 17 (NLQ), 12 x 9 (Utility), 10 x 9 (HS Draft), 8 x 9 (SS Draft)

Emulation, Interface and Memory

co-resident emulations	IBM 2480, Epson ESC/P, OKI MICROLINE
interface	Integrated USB and IEEE Parallel, Optional RS-232C Serial, Ethernet via OkiLAN 6020e
memory	128K Receive Buffer

Paper Handling

paper input	Single-part, Multi-part, Continuous forms, Cut sheet, Card stock, Envelopes, Labels
number of copies	4-part Rear Feed, 5-part Bottom Feed
thickness	0.011" (0.28mm) maximum

Warranty and Reliability

limited warranty	3-Year parts and labor, 2-Year printhead
MTBF	20, 000 hours (25% duty cycle/35% page density)
monthly workload	13, 000 pages at 25% duty cycle/35% density
printhead life	200 million characters avg. in 10 cpi utility mode at 25% duty, 35% page density
ribbon life	3 million characters (Utility mode)

Environmental

size	14.65" x 10.83" x 3.15" (37.2 cm x 27.5 cm x 8.0 cm)
net weight	10 lb. (4.5 kg)
acoustic noise	58 dBA
